Konica Auto S2: Find A Photoresistor Replacement

Hey fellow photography and electronics enthusiasts! Ever stumbled upon a classic camera, like the Konica Auto S2, only to find its light meter is on the fritz? You're not alone! I recently faced this exact challenge and decided to document my journey of finding a suitable replacement photoresistor. This guide is for anyone who wants to breathe new life into their vintage camera or simply learn more about photoresistors and light meters. So, let's dive in and get those classic cameras clicking again!

Understanding the Challenge: The Konica Auto S2 Light Meter

The Konica Auto S2 is a legendary rangefinder camera known for its sharp lens and reliable performance. However, like many cameras of its era, the light meter can fail over time. The heart of the light meter is a photoresistor, a component whose resistance changes with the amount of light it receives. In the Auto S2, this photoresistor is crucial for the camera's automatic exposure system. When the photoresistor degrades, the light meter readings become inaccurate, leading to over or underexposed photos. This is a common issue in vintage cameras, but thankfully, it's often fixable!

What is a Photoresistor and How Does it Work?

Before we jump into finding a replacement, let's understand what a photoresistor actually is. A photoresistor, also known as a light-dependent resistor (LDR) or photocell, is a passive electronic component whose resistance decreases when exposed to light. Think of it as a light-sensitive variable resistor. In darkness, the resistance is very high (often megaohms), and as light shines on it, the resistance drops significantly (down to a few hundred ohms or less). This change in resistance is what light meters use to measure light intensity.

Photoresistors are typically made from semiconductor materials like cadmium sulfide (CdS), cadmium selenide (CdSe), or lead sulfide (PbS). These materials are sensitive to specific wavelengths of light, and CdS photoresistors, in particular, were commonly used in older cameras due to their sensitivity to visible light. However, due to environmental concerns regarding cadmium, newer cameras often use alternative materials. Understanding the material and its spectral response is crucial when seeking a replacement.

Why Replace the Photoresistor?

The million-dollar question: why not just use an external light meter or a modern camera? Well, for many of us, the charm of a vintage camera lies in its original functionality. Using the built-in light meter preserves the authentic shooting experience and the camera's original design. Plus, there's a certain satisfaction in bringing an old piece of technology back to life! Replacing the photoresistor can restore the camera's automatic exposure capabilities, making it easier and more enjoyable to use, especially for those who prefer the simplicity of aperture-priority mode.

Identifying the Right Replacement: Key Characteristics

The trickiest part of this whole process is finding a photoresistor that matches the characteristics of the original. It's not as simple as just grabbing any photoresistor off the shelf. We need to consider several key factors to ensure the replacement works correctly with the Konica Auto S2's light meter circuit. Matching these characteristics will ensure accurate light readings and proper exposure.

1. Resistance in Darkness

The resistance of the photoresistor in complete darkness is a crucial parameter. This value determines the baseline reading of the light meter. If the dark resistance is too low, the meter might think there's more light than there actually is. Unfortunately, finding the exact specification for the original photoresistor in the Konica Auto S2 can be challenging, as this information isn't always readily available in the camera's service manual. However, through research and experimentation (more on this later), we can narrow down a suitable range. Typically, CdS photoresistors used in these cameras have a dark resistance in the megaohm range (1MΩ or higher).

2. Resistance in Bright Light

Conversely, the resistance in bright light is also important. This value determines how the photoresistor responds to high light levels. A lower resistance in bright light allows more current to flow through the meter circuit, indicating a brighter scene. Again, the exact value for the Auto S2's original photoresistor might be elusive, but a typical CdS photoresistor might have a resistance of a few hundred ohms in bright light. The key is to find a replacement that exhibits a similar range of resistance change from dark to bright conditions.

3. Spectral Response

The spectral response of a photoresistor refers to its sensitivity to different wavelengths of light. CdS photoresistors are most sensitive to visible light, which makes them suitable for light meters in cameras. However, different materials have different spectral responses. For example, some photoresistors are more sensitive to infrared light. To ensure accurate light readings, especially in various lighting conditions, the replacement photoresistor should have a spectral response similar to the original. This is where finding a CdS replacement can be beneficial, as it closely matches the original's characteristics.

4. Physical Size and Shape

Don't forget the physical dimensions! The replacement photoresistor needs to fit within the space constraints of the camera's light meter housing. Smaller photoresistors are generally easier to work with, but it's essential to ensure the light-sensitive area is adequately exposed to the incoming light. The shape of the photoresistor can also be a factor. Some cameras use circular photoresistors, while others use rectangular or other shapes. Try to find a replacement with a similar shape to simplify the installation process.

5. Response Time

The response time of a photoresistor is how quickly its resistance changes in response to changes in light intensity. Some photoresistors respond almost instantaneously, while others are slower. In a camera light meter, a faster response time is generally desirable, as it allows the meter to react quickly to changing light conditions. CdS photoresistors typically have a relatively fast response time, but it's still worth considering when selecting a replacement.

The Search Begins: Finding a Comparable Photoresistor

Now that we know what to look for, let's talk about where to find a suitable replacement. This can be a bit of a detective game, as the exact original part is unlikely to be available. However, there are several avenues to explore:

1. Online Electronics Suppliers

Your first stop should be online electronics suppliers like Digi-Key, Mouser Electronics, and Newark Electronics. These websites have vast inventories of electronic components, including various types of photoresistors. Use their parametric search filters to narrow down your options based on resistance, spectral response, and physical dimensions. Look for CdS photoresistors with a dark resistance in the megaohm range and a resistance in bright light of a few hundred ohms. Be sure to check the datasheets for detailed specifications and dimensions.

2. eBay and Vintage Electronics Sellers

eBay can be a treasure trove for vintage electronic components. Search for
